Balance 580

Combine and balance traffic across 5 WAN connections for enhanced performance and reliability.

Features:

• Multi-WAN Support – 5x Gigabit WAN ports for load balancing and failover.
• High-Performance SD-WAN – Seamlessly combines multiple connections for optimized speed and reliability.
• SpeedFusion Bonding – Aggregates bandwidth from different WAN sources for uninterrupted connectivity.
• Enterprise-Grade VPN – Supports SpeedFusion, IPsec, OpenVPN, and L2TP for secure remote access.
• Advanced Load Balancing – Intelligent traffic distribution across 5 WAN links.
• Cloud Management – Fully managed via Peplink’s InControl 2 platform.
• VLAN & Network Segmentation – Improves security and traffic management.
• Failover Protection – Ensures seamless transition to backup connections.
• Robust Security – Built-in firewall, intrusion detection, and content filtering.
• Scalability – Ideal for growing enterprise networks with high bandwidth needs.

Specifications:

• WAN Ports: 5 × Gigabit Ethernet WAN (Load Balancing & Failover)
• LAN Ports: 3 × Gigabit Ethernet LAN
• Throughput: Up to 2.5 Gbps
• VPN Performance: Up to 1.5 Gbps (SpeedFusion VPN)
• SD-WAN Features: SpeedFusion Bonding, Load Balancing, WAN Smoothing
• VPN Support: SpeedFusion, IPsec, OpenVPN, L2TP, PPTP
• Network Security: Firewall, Content Filtering, Intrusion Detection
• VLAN Support: Yes (Network Segmentation & Traffic Management)
• Cloud Management: Managed via InControl 2
• Power Supply: 12V – 56V DC
• Dimensions: 1.73” x 16.8” x 10.3” (44 x 426 x 262 mm)
• Weight: 9.48 lbs (4.3 kg)
• Operating Temperature: 32°F to 104°F (0°C to 40°C)
